THE UNIQUE AND PRACTICAL DESIGN OF PHIX COMPACT ENABLES MEASUREMENT OF PH OR REDOX POTENTIAL FROM THE MEDIA IN WHICH IT IS SUBMERGED.
The unique design of pHix Compact eliminates high impedance electrode connections and use of special hardware for mounting, and, with the large surface of the pHix Compact reference junction, the electrode is less sensitive to pollution.
All known issues - such as corrosion, moisture and oxidation due to high impedance - are practically eliminated with this construction.
This is one of the most user friendly pH transmitters on the market. The buffer adjustment of the pHix Compact is very easy to perform, which secures high repeatability.
pHix Compact is a ground-breaking and a very practical solution to customary pH transmitters. It is simple to install and easy to use. pHix Compact is your security of always measuring the pH value at the inlet of your plant, and thereby protecting the micro biologic organisms within the plant against incoming high pH fluids.
| Supply | 2-wire supply, 12 - 30 V DC |
| Material | FORTRON® (PPS) and/or stainless steel |
| Input, pH and mV | 0 -14 pH / - 1000 … + 1000 mV |
| Accuracy | ± 0,1 pH / 1 mV |
