C-Box Modbus Interface
Compatible with RS-485
The C-Box-S1 Modbus Interface enables a range of sensor control and data processing functions for different EKO sensors and is at the heart of the MS-90 Plus+ trackerless solar monitoring solution.
Sealed inside an IP65 all-weather case, with GPS receiver, and Modbus 485 RTU output, the C-Box Modbus processing interface enables a range of sensor control and data processing functions.
Working in tandem with the MS-90 DNI sensor and ISO 9060:2018 Class A leading MS-80SH pyranometer, the C-Box, is an essential component of the unique MS-90 Plus+ trackerless solar monitoring solution, allowing the system to accurately measure DNI, GHI, and to calculate DHI from measurement data and the position of the sun.
- For DNI, GHI & DHI measurements
- Output 0-1V / Modbus 485 RTU
- GPS Receiver
- IP65 all-weather case
| Communication interface | RS-485 Modbus |
| Channels | 2 units |
| Functions | DNI, GHI, DHI processing |
| Ingress protection IP | 65 |
| Operating temperature range | -40 to 80 °C |
| Voltage range | 12V |
| Power consumption | < 1 W |
