MI-530 Pyranometer Selector
Measure at different orientations
The MI-530 can be used with I-V Tracer like the MP-160 to help monitor and assess PV modules with varying positions and orientations.
The MI-530 is used to help monitor and assess PV modules with varying positions and orientations.
Up to x5 pyranometers can be used to measure irradiance in the plane of the PV module. The irradiance measurements of the sensor in the plane of array are then synchronised with the I-V measurement, using an I-V Tracer like the MP-160.
- Up to x5 pyranometers
- Compatible with the MP-160 I-V Tracer
| Measurement range Voltage | 0 to 0.03 V |
| Measurement range Current | 0 to 1 A |
| Measurement range Power | - |
| Operating temperature range | 0 to 40°C |
| Power supply | 100 to 240 VAC, 30W |
| Dimensions mm | 370 (W) x 350 (D) x 133 (H) |
| Weight | 5 kg |
| Input channels | 5 |
| Max. devices | 1 |
