Real-time optical measurement of BOD, COD, TOC, NO3 and many others…
Whether for process control, compliance monitoring or early warning of quality issues, up to date water quality information is critical. It is therefore surprising that the most common solution remains the collection of grab samples, which provides intermittent information and with substantial delay. The alternative, bringing the lab to the field using wet chemical analysers, comes at very high costs.
Applications
- Wastewater treatment plants (influent, effluent, process control)
- Industrial application (process water, wastewater treatment)
- Wastewater collection systems (load monitoring, corrosion protection)
- Water reclamation, reuse and irrigation
- Environmental Monitoring (surface water monitoring)
- Aquaculture and fish farming
- Landfill leachate monitoring
- Drinking water (source monitoring, process control, early warning of contaminations)
- Ground water management
- more…
Real-time results, directly from the process
- Real time sensor
- In-situ installation (no sampling or sample pretreatment)
- 100% optical (no reagents, long term stable, simple to use)
- Small size sensor probe (allows in-situ and in-pipe installations)
- Minimal operating costs (no consumables, automatic cleaning, minimal maintenance)
Highly robust
- Suited for high temperature applications (0 – 110oC)
- Available in both stainless steel and titanium, quartz windows
- Full spectral measurement for high specificity and compensation
Unparalleled flexibility
- Multiple parameters from one device
- Software supports development of own parameters and virtual sensors
- Variable pathlength – measurement range can be adjusted to the matrix
- Standard ATEX certification class III (ATEX class II optional)
- Wide range of communication interfaces
- Controller with full PLC functionality
Smart sensor solution
Fully integrated in the Eijkelkamp Web Portal for online visualization of measurement results and integration with your other monitoring solutions. Supports remote calibration and device configuration.
| Parameter | Measurement Range* | Parameter | Measurement Range* |
| BODeq | 0 - 2000 mg/L | Turbidity | 0 - 2000 NTU |
| CODeq | 0 - 12000 mg/L | TSS | 0 - 15000 mg/L |
| NO3-N | 0 - 100 mg/L | Colour | 0 - 100 Hazen |
| TOCeq | 0 - 5000 mg/L | Ozone | 0 - 10 mg/L |
| DOCeq | 0 - 3000 mg/L | Phenol | 0 - 20 mg/L |
| SAC254/UV254 | 0 - 25-- Abs/m | Fingerprint Alarm |
* dependent on application, indicative ranges only
