Spectrum Technologies

FieldScout SC 900 Soil Compaction Meter

Soil & CropsSoil Stress & Compaction

The SC 900 meter now includes the brand new 3/4" cone tip, as well as improved handling of insertion errors. The 3/4" tip is appropriate for coarse soils. These new features took effect with units shipped after January 1, 2012. Meters acquired prior to 2012 can be upgraded by purchasing the SC900 Upgrade Package (Item #6110FSUP, see purchase table above). The upgrade includes a microcontroller chip with updated firmware, a 3/4" cone tip, new depth target, and updated User's Manual.

Quantity

Specifications

Measurement Units	Cone Index (PSI or kPa)
Resolution	1 in (2.5 cm), 5 PSI (35 kPa)
Accuracy	± 0.5 in (1.25 cm) Depth, ±15 PSI (103 kPa) Pressure
Range	0 to18 in (0 to 45 cm), 0 to 1,000 PSI (0 to 7,000 kPa)
Battery/Life	4 AAA alkaline batteries; approximately 12-month life
Data Logger Capacity	772 profiles without GPS; 579 profiles with GPS
