MC-500 Moisture Meter

ClimateMoisture Meters

The MC-500 allows moisture detections in wood down to a depth of approximately 40 mm. It is designed for quick-response detection of moisture content in wood and building materials as well as locating wet areas in floors, roofs and walls made of homogeneous material.

Quantity

Overview

Pin-less & non-destructive: Capacitance measurement using a high frequency dielectric field
Used on different materials such as wood, concrete, cement wash floor, brick, plaster, gypsum board, clinker and clay floor tiles, sandstone, marble, etc.
Quickly indicates the moisture content of materials
Moisture detection down to a depth of Approximate.. 40 mm
Low battery indication
Impact resistant ABS housing
Complete with 9 V battery

Specification

Measuring range	0 – 30 % moisture content
Field penetration depth	30-40 mm Depending om material density
Working conditions, temp / RH	0 to +50° C / 0 to 80 % (non condensing)
Storage temperature	-20 to +70°C
Display	3 ½- digit, 13 mm high LCD-display
Resolution	0,1%
Power supply	9 V alkali battery (type IEC 6F22)
Power consumption	5 mA
