Q-S151 CO2 Analyzer 0-2000ppm

Soil & CropsPhotosynthesis Chlorophyll & Respiration
Q-S151 Infrared CO2 Analyzer is a non-dispersive infrared CO2 analyzer that measures CO2 in 0 to 2000 ppm range with 1 ppm resolution. Dependable technology rugged and modular for easy fit in our Q-Box Packages or for stand alone use.
Quantity
1

Overview

  • Switchable ranges of 0 – 500 ppm and 0 – 2000 ppm CO2
  • 1 ppm CO2 resolution on digital display
  • Non-dispersive infrared technology
  • Modulated infrared light source = no moving parts
  • 0 – 5 V analog output at both range settings
  • Optional battery pack for field use
  • Compact and portable

Specification

Maximum gas flow rate 650 mL/min
Measurement range (LCD display) 0 – 1999 ppm
Analog output, low sensitivity 0 – 2000 ppm
Analog output, high sensitivity 0 – 500 ppm
Accuracy ± 1 ppm
Maximum drift (per year) ±100 ppm
