Step-In FytoScope FS 3400

Soil & CropsPhotosynthesis Chlorophyll & Respiration
Step-In FytoScope FS-SI are plant growth chambers that utilize Light Emiting Diodes (LEDs) as a sole light source. Thus excellent spectral quality with high irradiance is provided for plant physiology applications. Due to versatile construction, these FytoScopes may be used for growing of diverse plants: from Arabidopsis to wheat, corn or rice.
Quantity
1

Overview

  • Lighting: adjustable in intensity (from 0 % to 100 %), timing, modulation, and diurnal cycling
  • Temperature: maximum +40 °C; minimum +10 °C (lights ON, ambient room temperature up to 35 °C); optionally minimum down to 0 °C
  • Relative humidity adjustable from 40 % to 80 % (independent on light intensity)
  • LED technology with minimum undesired plant heating
  • White LED illumination with supplementary FAR LEDs for excellent plant growth
  • PPFD up to 1,000 µmol.m-2.s-1 at the distance of 50 cm (higher intensity as an option)
  • Rapid modulation of irradiance simulating light flecks
  • Precise adjustment of the light intensity from 1 to 100 %
  • Homogeneous illumination over the whole cultivation area
    of 0.88 m2 (model FS-SI 3400) respectively 1.32 m2 (model FS-SI 4600) - additional growing space at the bottom
  • Adjustable shelving
  • Step-in unit with inside capacity of 3400 l (model FS-SI 3400); 4600 l (model FS-SI 4600) - other volumes on request
  • For extra protection of investigated plants, the Fytoscope features both hardware and software protection against undesired overheating of the inside environment
  • Incorporated measuring of chlorophyll fluorescence (optional)

Specification

Controlled Temperature Range +10°C to +40°C (independent on light intensity; ambient room temperature up to +35°C), optionally: 0°C to +40°C
Humidification ultrasonic humidifier (not hot steam)
Dehumidification adsorption
Controlled Humidity Range 40 to 80 % (independent on light intensity)
Weight 650 kg
Air Ventilation 1200 l/hour
Power/Power Input 6,5 kW

Downloads

3400 Download3400
