UV-VIS/UV Sensor

WaterWater Quality Measurement

Digital, optical senor for the IQ SENSOR NET CarboVis® 700 IQ (TS): Spectral sensor with integrated ultrasonic cleaning for the chemical-free measurement of the organic load and suspended solids concentration

Quantity

Overview

Features:

Calibration-free
Extremely robust
Minimal cleaning effort

Optimal for the measurement of TOC and DOC in the inlet/effluent of municipal wastewater treatment plants.

Thanks to its innovative optics and spectral measuring technique, this is sensor is calibration-free. An optimized referencing ensures an excellent zero point and long-term stability. This ensures reliable measuring results! The maintenance-free WTW ultrasonic cleaning technology reduces the manual cleaning effort to a minimum.

Specification

Model	CarboVis 701 IQ	CarboVis 705 IQ	CarboVis 701 IQ TS	CarboVis 705 IQ TS
Measuring Method	Spectral measurement in the UV-VIS range (200-720nm)
Measuring Gap	1mm	5mm	1mm	5mm
Measuring Range and Resolution	Refer to Technical Specifications Sheet
Flow Rate	≤ 3 m/s
Pressure Resistance	Maximum 1 bar (incl. sensor connection cable)
Electrical Connections	2-wire shield cable with quick fastener to sensor
Electromagnetic Compatibility	EN 61326, Class B, FCC Class A Intended for indispensable operation
Certifications	CE
Mechanical	Housing: Titan Grade 2, PEEK; Window: Sapphire glass Protection class: IP 68
