Wind Cups and Vane Anemometer

ClimateMeteorological Station & Sensors

Combined wind speed and wind direction sensor. This sensor range includes, in a single apparatus, transducers for both wind speed and wind direction measurement. Its use simplifies installation requirements, other than being smaller, lighter and cheaper than the general 2-sensors kit. Accuracy and thresholds are anyway near to be comparable with a 2-sensors cup and vane kit alternatives. Different data output signals are available.

Quantity

Overview

Highlights

Alternative signal outputs: (Hz+0-1 V), 0-5 V, 4-20 mA, RS485 Modbus;
Wide power supply: 9-30 Vac/dc;
Simple to install on pole 5 cm diameter;
High demage threshold up to 75 m/s;
Optional cable up to L.100 m In house;
ISO17025 accreditate calibration laboratory.

Available Models

	DNA121	DNA821 DNA821.1 DNA821.2	DNA827	DNA921
Wind Speed Output	0 - 833 Hz	4 - 20 mA	0 - 5 VDC	RS485
Wind Speed Measuring Range	0...75 m/s (demage limit)	DNA821: 0...60 m/s DNA821.1: 0...50 m/s DNA821.2: 0...75 m/s	0...60 m/s	0...60 m/s
Wind Direction Output	0...1 Vdc	4...20 mA	0...5 Vdc	RS485
Protocol	-	-	-	Modbus RTU®, TTY-ASCII
