06.06 Hand Penetrometer For Top Layers

Soil & CropsIn-Situ Soil Physical Research

The hand penetrometer for top layers is a device that is used to determine the penetration resistance of top layers. Because of the limited overall length of the device, the hand penetrometer can also be used for horizontal measurement, for instance in the walls of profile pits.

Quantity

Benefits

Small cones allow for shallow measurements
Good measurements at 15x cone diameter
Drag pointer for easy read-out
Durable construction
Factory calibrated exchangeable springs

Specifications

GENERAL SPECIFICATIONS

Angle of cone	30 °
Connection	screwthread
Maximum measuring depth	0.6 m
Measuring accuracy	< +/- 8%
Product material	stainless steel, iron, other material
Cone surface range	0.25 , 0.5 cm²
Maximum force	1500 @ 0.25 cm² kPa
Measured parameters	penetration resistance
Measuring range	0...6000 kPa
Reading accuracy	1%
