Z6 Counting Device

WaterLevel Measurement & MonitoringFlow & Velocity Measurement & MonitoringSignal Processing

The compact, fully electronic SEBA Z6 counting device is therefore equipped with an easy-to-read, 5-digit LCD with a large keypad and a shoulder strap. An internal 9V block battery ensures a long service life. In addition, there is the possibility to equip the Z6 with a block-battery and recharge it on-the-go with a car charger.

Quantity

Overview

Versatile:
The basic Z6 version, detects impeller pulses according to fully adjustable preset times and then adds them. Optionally, the desired number of pulses can be defined using the membrane keypad with the Z6-I instead of the time delay. The Z6-V is very comfortable and offers the user the possibility to directly display the flow rate. For this purpose, up to 20 wing calibration equations can be stored in the counter and pre-selected for the measurement.

Last but not least:
All user settings can be conveniently made and stored on the device itself or with a PC / laptop via the RS232 interface.

Specification

Z-6

Pulse Frequency	max. 40 pulses/s
Measuring Accuracy	0.01 s (time measurement) 1 pulse (pulse counting)
Input Signal	Contact input
Connections	2 x 4 mm socket for connecting cables wing - counting device
Time Preset	free pre-definable 10 seconds steps

Z6-I

Pulse Preselection	Additionally freely pre-definable in 10 pulse increments

Z6-V

Storage Space	Storage of up to 20 calibration equations and additional indication of flow rate in cm/s

Housing

Material	Anodised aluminum
Dimensions	122x117x45mm (LxWxH)
Display	5-digit LCD display
Membrane Keyboard	6 function keys
Protection Class	IP65
Communication Interface	RS232
