Colloidal Borescope

WaterFlow & Velocity Measurement & Monitoring

The Geotech Colloidal Borescope accurately measures groundwater velocity and direction in real-time. Using proprietary technology, the Colloidal Borescope incorporates a down-well sensor set to depth-specific intervals and a live-view AquaLITE software that captures and records thousands of data points per minute yielding statistically assured preferential flow data.

Quantity

Overview

Observes flow at a pore scale for measuring velocities ranging from 0 to 30 mm/sec
Generate flow and velocity models using existing wells – avoiding added costs associated with installing additional wells or piezometers
Identify flow direction and velocity in real-time
Capture statistical summary report that includes well number, date, vector analysis and more

Components

Borescope Probe – fully integrated colloidal view video microscope with magneto-resistive digital compass enclosed in a protective 300 series stainless steel housing.
Bulkhead Down Well Cable – reinforced composite video underwater camera cable incorporating Kevlar longitudinal strain relief and polyurethane outer jacketing. Down well cable lengths are available from 100' (30m) to 1000' (305m)
Geotech Portable Reel – transporting and storing the down well cable and Borescope probe
Camera Control Unit – featuring camera and lighting power supplies, serial data connection for digital compass via USB, and transmission of live down well video using a 54mm express card
Extension Cable – connects camera control unit to the portable hand reel, used with systems that include 200 feet or more of down well cable
AquaLITE Software – allows user to live-view water flow direction, velocity or combined graphs, and statistical summary reporting. AquaLITE also features fully configurable video signal quality, ground water quality, and other aquifer characteristics
Operation Manual – detailing full instructions on how to operate the instrument

Specification

Applications	2" (5.8 cm) or larger well diameter
Maximum Operating Depth & Submergence	1,000' (305 m)
AC Power Requirements	90-240VAC, 47 to 63 Hz. 7W Service requirement <1A
DC Power Requirements	10 to 16V DC @ <1A
Probe Size	21.25" L x 1.75" OD (54 cm L x 4.5 cm OD)
Probe Weight	5 lbs (2.5kg)
Probe Housing Material	300 series stainless steel
Window Material	Sapphire
Camera Control Unit Size	3.98" W x 7.89" L x 3.16" H (10 cm W x 20 cm L x 8 cm H)
Camera Control Unit Weight	2 lbs. (.9 kg)
Cable Size	0.375" OD (0.9cm) Customer specified length from 100' to 1000' (30.5m to 305m)
Cable Jacket Material	Urethane (composite cable material ROHS compliant)
Electrical Component Material	Non-ROHS compliant (dispose of properly)
Operating Temperature Range	-10° to 45° C (14° to 113° F)
Camera Field of View	2.5 mm x 2 mm
Depth of Focus	0.2mm
Min. Groundwater Velocity	0 mm/s
Max. Groundwater Velocity	30 mm/s
Minimum Particle Size	10μm
Maximum Particle Size	Within camera field of view
Heading Accuracy	1.0° RMS typical
Heading Resolution Output Data	0.1°
Heading Hysteresis Output Data (1s)	±0.3°
Cable Left Capacity	426 pounds (193 kg)
Compass Resolution	1°
Compass Accuracy	±1°
