Valmet Low Solids Measurement - Valmet LS

Features

Valmet LS device can be connected online to the process and it is possible to measure continuous sample flow through the system by utilizing an integrated centrifugal pump. The system has two LED light sources. When the sample passes through the measurement cell, the absorption, scattering, and depolarization signals from both light sources are measured.

Valmet LS continuously measures both the entrained air index, which indicates overdosing of polymer and the suspended solids content within the range of zero to 5,000 mg/l. If bigger, please contact Valmet personnel. The Valmet LS measurement system deaerates, filters, and measures the process solids along with possessing self-cleaning capabilities to keep the measurement optics clean. The measurement cell has an extremely strong sapphire glass with high optical properties. The cell and sample lines are automatically cleaned at given intervals.

Benefits

• Optimization of the capacity of the wastewater plant
• Polymer savings
• Optimization of the dewatering machine
• Reduced laboratory/sampling work
• Faster polymer test runs and selection
